WUXI GLOBAL POWER TECHNOLOGY CO.,LTD
ผู้ใช้ต้องมาก่อน, ยึดมั่นความซื่อสัตย์; สร้างแบรนด์ GP ด้วยคุณภาพ, สร้างชื่อเสียงด้วยบริการ
รายละเอียดสินค้า:
การชำระเงิน:
|
| ประเภทเครื่องกำเนิดไฟฟ้า:: | ไมโครคอมพิวเตอร์ควบคุมเครื่องกำเนิดไฟฟ้าอัตโนมัติ | พลังงานสแตนด์บาย: | 176kW / 220kVA |
|---|---|---|---|
| จัดอันดับช่วงปัจจุบัน: | 288A | ความเร็วและความถี่: | 1500 / 1800prm , 50 / 60Hz |
| ชั้นฉนวน: | ชม | ระบบควบคุมแบบรวม: | ประกอบบนฐานลื่นไถล |
| โหมดกระตุ้น: | ตื่นเต้นในตัวเอง | ตลาดส่งออก: | เอเชียตะวันออกเฉียงใต้, ตะวันออกกลาง, กลาง Ais, แอฟริกาใต้และอื่นๆ.... |
| แรงดันไฟฟ้าที่ได้รับการจัดอันดับ: | 220V/380V, 230V/400V, 240V/415V | วิธีการติดตั้ง: | ที่ตายตัว |
| เน้น: | marine diesel genset,Emergency Generator Set |
||
General Features:
1. Generator can be used as Main Marine generator
2. CCS approved (IACS-International Association Of Classification Societies)
3. Cooled by heat exchanger / radiator
4. Adopt CUMMINS Engine
5. Marathon single-shaft alternator standard , Stamford alternator is optional
6. Parallel connection: Two and more normal marine generating sets can transfer loading without stopping ,and can realize parallel.
7. Standard SAE coupling the engine and alternator
8. With efficiency anti-vibration devices
9. Cold rolled steel one time molded base
10. High reliability , low use and maintenance cost
Complete Cummins Marine Diesel Generator including marine diesel engine, alternator, heat exchanger+water pump or radiator, standard control system, circuit breaker, absorber, filters, testing report, marine class certificate, user books and other accessories etc..
CUMMINS Marine Genset Model List :
Specification:
| 1. Specification of genset | ||||||||
| Gensets model | CCFJ160J | |||||||
| Rated power | 160KW | |||||||
| Rated voltage | 400/230V | |||||||
| Rated current | 288A | |||||||
| Rated frequency(HZ) | 50 | |||||||
| Rated speed | 1500rpm | |||||||
| Power factor | 0.8(lagging) | |||||||
| Dimensions(mm) (L×W×H) | 2400*900*1550 | |||||||
| Genset weight(kg) | 1900 | |||||||
| 2. Specification of diesel engine | ||||||||
| Engine brand | Cummins | |||||||
| Engine model | 6LTAA8.9-GM200 | |||||||
| Number of Cylinders | 4 | |||||||
| Cylinder arrangement | Vertical in-line | |||||||
| Cycle | Four stroke | |||||||
| Aspiration | Turbocharged | |||||||
| Rated power | 200KW | |||||||
| Rated speed | 1500rpm | |||||||
| Starting Method | DC24V electrical starting | |||||||
| Speed Governor | Electronic | |||||||
| Cooling System | By sea water heat exchanger | |||||||
| 3. Specification of alternator | ||||||||
| Alternator brand | Stamford | |||||||
| Alternator model | UCM274J/200 | |||||||
| Number of Phase | 3 | |||||||
| Connecting Type | 3 Phase and 4 Wires | |||||||
| Number of Bearing | 1 | |||||||
| Protection Grade | IP23 | |||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | |||||||
| Insulation Class | H | |||||||
Global Power Service:
Ettes Power provides a full line of brand new and high quality products. Each and every unit is strictly factory tested. Warranty is according to our standard conditions: 12 months or 1000 running hours, subject to the earlier one. Furthermore, Ettes Power will provid life-span technical support and spare parts at manufacture prices.
1. In manufacturing of power generators, GLOBAL POWER is able to draw on an experience
of more than 10 years. Our total production capacity is about 20,000 units per year.
2. The power generator sets are designed for continuous power supply and have proved 10,000
fold around the world in various applications on every continent.
3. Except standard products, we also provide customized design service for you, design generator
sets as per your specific requirements.
4. We provide professional & in time service after sale.
Warranty:
