WUXI GLOBAL POWER TECHNOLOGY CO.,LTD
ผู้ใช้ต้องมาก่อน, ยึดมั่นความซื่อสัตย์; สร้างแบรนด์ GP ด้วยคุณภาพ, สร้างชื่อเสียงด้วยบริการ
รายละเอียดสินค้า:
การชำระเงิน:
|
| ไพร์ม พาวเวอร์ (kVA): | 4.5 | กำลังไฟสแตนด์บาย (กิโลวัตต์/กิโลวา): | 5 |
|---|---|---|---|
| แรงดันไฟฟ้า(V): | 220 | แรงดันไฟฟ้า (V): | 400/230 |
| การกำหนดค่า: | เฟสเดียวสามลูป | บรรจุุภัณฑ์: | บรรจุโฟมพลาสติกหรือกล่องไม้อัด |
| ระดับเสียงรบกวน (7ม.) เดซิเบล(เอ): | 97 | ||
| เน้น: | quiet portable generator,portable backup generator |
||
For Home / Office Used Silent / Open Diesel Generator Set 1.7kva - 12kva 50HZ / 60HZ
Features and Benefits
1. Powerful Lees four-stroke engine
Lees commercial-grade OHV engines are reliable, easy-to-start and incredibly rugged.
2. Reliable and stable output
Applied the improved AVR (automatic voltage regulator), which not only
can smooth the output but also provide reasonable protection against
the overload of the whole set
3. Competitive economic operation
The high efficiency combustion system is designed to reduce the
consumption and operation cost
4. Qualified breaker, electronic elements
Ensuring high quality of generator, protect the generator from being overload
5. Compact design
Provides unparalleled power to weight ratio
6. Large steel fuel tank
For durability and extended running time
Technical Specifications:
|
Frequency(Hz) |
50 |
60 |
|
|
Rated Output(kVA) |
4.5 |
5.0 |
|
|
Max Output(kVA) |
5.0 |
5.5 |
|
|
Voltage(V) |
220 |
220 |
|
|
Current(A) |
19.9 |
23 |
|
|
Configuration |
Single phase, three loops |
||
|
Factor |
1.0 |
||
|
Insulation Class |
B |
||
|
Pole |
2 |
||
|
Phase |
1 |
||
|
Excitation Mode |
Self-excitation & constant voltage(AVR) |
||
|
Panel type |
General panel |
||
|
output |
socket |
2pc single phase socket |
|
|
|
Connection Pole |
Without |
|
|
|
DC12V Output |
Connection pole output |
|
|
Dimension ((L *W*H) |
750*500*660 |
||
|
Dry weight(kg) |
100 |
||
|
Working assorting weight (Kg) |
105 |
||
|
Noise level(7m)dB(A) |
97 |
||
|
Frame type |
Open frame |
||
Engine
|
Model |
GP 186FA |
|
|
Engine type |
Vertical,4 stroke, Air cooled, direct injection |
|
|
Displacement(mL) |
418 |
|
|
Cylinder NO.-bore×stroke (mm) |
1-86×72 |
|
|
Rated power(kW) |
5.7 |
6.3 |
|
Rated rotation speed(r/min) |
3000 |
3600 |
|
Fuel consumption ( g/kW.h) |
275.1 |
281.5 |
|
Capacity of Fuel Tank (L) |
15 |
|
|
Starting System |
Electric starter |
|
|
Compression ratio |
19:1 |
|
|
Continuous working hours(hr.) |
8 |
|
Product superiority:
Our Service:
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China. We can drive to pick you up and visit our factory.
2. Suggest the best choice or referential suggestion based on customers’ information. Answer all questions about the product from customer.
3. Build customers’ profiles, follow-up service, make regular calls on customers.
PHOTOS:
Our advantages:
1.Inspection
1) Each engine shall be tested at manufacturer’s workshop to certify the engine output according to present standard and fuel consumption in accordance with the site operating condition specified by purchaser on the specification datasheet.
2) All relevant information drawings pertinent to the testing and test procedure shall be transmitted to the purchaser in advance of the test date notification.
3) All accompanied documents are corresponding to the actual situation of generators, including the Qualified Certificate, Parameters and the Performance Index.
2.Guarantee
1) Guarantee Period: One year or 1000 running hours whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.
For Home / Office Used Silent / Open Diesel Generator Set 1.7kva - 12kva 50HZ / 60HZ
If you have interest , just contace me !
