320kw 400kva Perkins diesle generator 50Hz, automatic starter with DSE4620 controller
รายละเอียดสินค้า
| ไพรม์ พาวเวอร์: |
320/400 กิโลวัตต์/กิโลวา |
เครื่องยนต์: |
เพอร์กินส์ |
| แบบอย่าง: |
2206C-E13TAG3 |
หมายเลขกระบอกสูบ: |
6 |
| การกระจัด: |
12.5 ล |
การควบคุมความเร็ว: |
อิเล็กทรอนิกส์ |
| ความจุของแบตเตอรี่: |
24v100ah |
เสียงรบกวนขณะวิ่ง db(A)/7m: |
75 |
| เน้น: |
brushless synchronous generator, engine generator set |
320kw 400kva Perkins diesle generator 50Hz, automatic starter with DSE4620 controller
Standard Supply Scope:
- Diesel engine with Alternator
- Standard Accessory: Exhaust Silencer, Flexible pipe, Battery & Connenct wire, Operation Manual.
- Control system will use Deep Sea DSE AMF module, LCD display all engine parameter, alternator parameter, and fully alarm & protection function.
- Radiator is standard , Strat battery and charger
Technical Specifications :
| Prime Power (kw/kva) |
320/400 |
| Standby Power (kw/kva) |
352/440 |
| Rated Voltage (V) |
400/230 |
| Voltage Recovery Time |
≤1S |
| Rated Current (A) |
576 |
| Rated Frequency (Hz) |
50 |
| Frequency Recovery Time |
≤5S |
| Wave Distortion |
≤5%, sine wave |
| Running Noise db(A)/7m(Silent type) |
75 |
| Battery capacity (V-Ah) |
24V 100Ah |
| Open Type-Dimension (L*W*H) (mm) |
3200*1150*1900 |
| Open Type-Weight (kg) |
2875 |
| Soundproof Type- Dimension (L*W*H) (mm) |
4250*1500*2300 |
| Soundproof Type-Weight (kg) |
7225 |
| Fuel Tank Capacity(L) |
800 |
| Continuous Running Time(hr.) |
8 |
- Tightly structure, excellent design and craft
- Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)
- Self-diagnostic capability simplifies troubleshooting
- LCD display shows system status and setup information
- Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality
- Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.
- Enclosed muffler for added quietness
- Service and maintenance accessible through easy-latch side service door.
Perkins Engine:
Model 2206C-E13TAG3
| Engine brand |
Perkins |
| Output Power (kw) |
392 |
| Cylinder No. & Config. |
6, in-line |
| Combustion System |
direct injection |
| Compression Ratio |
16.3:1 |
| Displacement (L) |
12.5 |
| Bore X Stroke (mm) |
130*157 |
| Engine Speed (r/min) |
1500 |
| Speed Governing |
Electronic |
| Starting System |
24V DC Electric |
| Filter System |
Dry oil filter/Fuel filter/Oil filter |
| Cooling system |
Water-cooled |
| Coolant capacity (L) |
51.4 |
| Fuel Consump. (g/kw·h) |
206 |
| Oil Capacity (L) |
40 |
feature:
- Six-cylinder, water-cooled, in-line diesel engine
- Efficient fuel system for max power output and durability
- Large-capacity air cleaner
- Cost effective, fuel efficient and reliable performance
- Functional engine with compact structure
- Excellent after-sales service and sufficient spare parts supplying
- Easy installation and ready access for routine maintenance
Meccalte Alternator:
Model ECO40-1S/4
| Rated Power (kw) |
320 |
| Excitation System |
Brushless, self-exciting |
| Voltage Regulation Mode |
AVR |
| Connection Type |
3phase,4wires,”Y” connection |
| Pole No. |
4 |
| Rotation Speed (r/min) |
1500 |
| Temperature Rise (℃) |
125 |
| Insulation class |
H |
| Voltage Regulation (0 load) |
≥95%～105% |
| Voltage accuracy |
≤±1% |
| Protection Grade |
IP23 |
| Telephone Influence Factor |
TIF＜50 |
| Harmonic Coefficient |
THF＜2% |
|
feature:
- Advanced automatic voltage regulator (AVR) control for trouble-free operation under the most demanding conditions
- 2/3 pitch winding as standard, to avoid excessive neutral currents
- Single or two bearing construction with dynamically balanced rotor and sealed-for-life bearings
- Easy access for installation and maintenance
- IP23 as standard
- Self-excited control system
- Resist of corruption of oil and acid
Control system :
DSE4620
features:
- Using microprocessor as a core, graphics LCD with big screen and backlight, key touch for operation
- Security password-protected programming levels
- All parameters use digital modulation, with higher reliability and stability
- Built-in speed/frequency detecting units can accurately judge the states such as crank success and over speed
- Power supply range is wide, accommodating to different starting battery voltage environment
- Built-in watch dog can never be dead halt, ensuring smooth program execution
- Modular configuration design, inserted type connection terminals, flush type installation, compact structure, easy installation
Our Picture :
Select Supply Scope:
- Silent ,Mobile,Container,weatherproof types canopy and trailer
- Connect to main ,all panels:Circut Breaker,ATS,etc
- Water & oil heater, oil-water separator, air breaker, base fuel tank.
Genset Construction :
- All our gensets are built with original diesel engines coupled to a brushless alternator mounted onto a steel base frame with channel supports on anti-vibrating rubber mountings.
- The fuel tank is fabricated of mild steel and is incorporated into the base frame. The size of the tank is dependent on the size of the generator.
Features and benefits:
- Tightly structure, excellent design and craft
- Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)
- Self-diagnostic capability simplifies troubleshooting
- LCD display shows system status and setup information
- Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality
- Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.
- Enclosed muffler for added quietness
- Service and maintenance accessible through easy-latch side service door.
Guarantee for Our Generators:
- Guarantee Period: One year or 1000hours whichever comes first.
- During the guarantee period, the spare-parts will be sent through your shipping agency in China.
- Spare-parts can also be sent thought FEDEX or DHL, but the shipping cost will be charged on both sides for 50%.
- 24 hours service hot-line is available for customers.
