WUXI GLOBAL POWER TECHNOLOGY CO.,LTD
ผู้ใช้ต้องมาก่อน, ยึดมั่นความซื่อสัตย์; สร้างแบรนด์ GP ด้วยคุณภาพ, สร้างชื่อเสียงด้วยบริการ
รายละเอียดสินค้า:
การชำระเงิน:
|
| จัดอันดับความถี่: | 50/60 เฮิรตซ์ | แรงดันไฟฟ้า(V): | 115/120 |
|---|---|---|---|
| การกำหนดค่า: | เฟสเดียวสามลูป | พิกัดเอาท์พุท (kVA): | 2.8/3.0 |
| ปัจจัย: | 1.0 | ระดับเสียงรบกวน (7ม.) เดซิเบล(เอ): | 72 |
| น้ำหนัก: | 140 กิโลกรัม | สี: | ปรับแต่ง |
| เน้น: | trailer mounted diesel generator,marine diesel genset |
||
3.2Kva Energy Saving Single Phase Gasoline Generator Set With 14 Continous Working Hours
Features and Benefits
1. Powerful Lees four-stroke engine
Lees commercial-grade OHV engines are reliable, easy-to-start and incredibly rugged.
2. Reliable and stable output
Applied the improved AVR (automatic voltage regulator), which not only
can smooth the output but also provide reasonable protection against
the overload of the whole set
3. Competitive economic operation
The high efficiency combustion system is designed to reduce the
consumption and operation cost
4. Qualified breaker, electronic elements
Ensuring high quality of generator, protect the generator from being overload
5. Compact design
Provides unparalleled power to weight ratio
6. Large steel fuel tank
For durability and extended running time
Technical Specifications:
| Frequency(Hz) | 50 | 60 | |
| Rated Output(kVA) | 2.8 | 3.0 | |
| Max Output(kVA) | 3.2 | 3.2 | |
| Voltage(V) | 115/230 | 120/240 | |
| Current(A) | 24.4/12.2 | 27.5/13.8 | |
| Configuration | Single phase, three loops | ||
| Factor | 1.0 | ||
| Insulation Class | B | ||
| Pole | 2 | ||
| Phase | 1 | ||
| Excitation Mode | Self-excitation & constant voltage(AVR) | ||
| Panel type | General panel | ||
| output | socket | 2pc single phase socket | |
| Connection Pole | Without | ||
| DC12V Output | Connection pole output | ||
| Dimension ((L *W*H) | 830*532*740 | ||
| Dry weight(kg) | 140 | ||
| Working assorting weight (Kg) | 154 | ||
| Noise level(7m)dB(A) | 72 | ||
| Frame type | Silent frame | ||
Engine
| Model | GP 178F | |
| Engine type | Vertical,4 stroke, Air cooled, direct injection | |
| Displacement(mL) | 296 | |
| Cylinder NO.-bore×stroke (mm) | 1-78×62 | |
| Rated power(kW) | 3.68 | 4.0 |
| Rated rotation speed(r/min) | 3000 | 3600 |
| Fuel consumption ( g/kW.h) | 276.1 | 285.6 |
| Capacity of Fuel Tank (L) | 15 | |
| Starting System | Electric starter | |
| Compression ratio | 20:1 | |
| Continuous working hours(hr.) | 14 | |
